20H
Blackburn®* Actual product may vary from image
Type H - High Strength Split-Bolt Connector, Conductor Range for Equal Main and Tap 2/0 Str-2 Sol, Conductor Range for Min Tap with One Max Main 14 Sol
Details
MFG PART #:20H
McMc Part #:TBCO20H
UPC #:783786200153
Inventory
$3,746.06 C
Details
MFG PART #:20H
McMc Part #:TBCO20H
UPC #:783786200153
Inventory
Attributes
Features
Documentation
Attributes
Brand:Blackburn®
ETIM:EC000491
Type:Type H High Strength
Conductor Type:Solid/Stranded Copper
Conductor Size:2 to 2/0 AWG
Bolt Size:7/8 x 1-13/16 in
Specifications:0.443 in Split, 1-1/16 in Hex Nut
Material:Bronze Alloy
Color:Metallic
Features
| Bolt and nut of high-strength corrosion-resistant bronze alloy |
| Pressure bar is copper through 40H, copper alloy for 350 kcmil and above |
| Bolt and nut of hex design up to 350 kcmil |
| Split-bolt connector made of metallic bronze alloy for use on copper conductors |
| 14 AWG solid conductor range min tap with one max main |
| 2/0 AWG stranded to 2 AWG solid conductor range for equal main and tap |
| 25 pieces/pack |
