30H
Blackburn®* Actual product may vary from image
Type H - High Strength Split-Bolt Connector, Conductor Range for Equal Main and Tap 4/0 Str-2 Sol, Conductor Range for Min Tap with One Max Main 6 Sol
Details
MFG PART #:30H
McMc Part #:TBCO30H
UPC #:783786200160
Inventory
$ C
Details
MFG PART #:30H
McMc Part #:TBCO30H
UPC #:783786200160
Inventory
Attributes
Features
Documentation
Attributes
Brand:Blackburn®
Bolt Size:1 x 2-5/32 in
Color:Metallic
Conductor Size:2 to 4/0 AWG
Conductor Type:Solid/Stranded Copper
ETIM:EC000491
Material:Bronze Alloy
Specifications:0.58 in Split, 1-5/16 in Hex Nut
Type:Type H High Strength
Features
| Bolt and nut of high-strength corrosion resistant bronze alloy |
| Pressure bar is copper through 40H, copper alloy for 350 kcmil and above |
| Bolt and nut of hex design up to 350 kcmil |
| Split-bolt connector made of metallic bronze alloy for use on copper conductors |
| 6 AWG solid conductor range min tap with one max main |
| 4/0 AWG stranded to 2 AWG solid conductor range for equal main and tap |
| 25 Pieces/Pack |
