350M
Blackburn®* Actual product may vary from image
Type H - High Strength Split-Bolt Connector, Conductor Range for Equal Main and Tap 350 kcmil-250 kcmil, Conductor Range for Min Tap with One Max Main 1/0 Str
Details
MFG PART #:350M
McMc Part #:TBCO350M
UPC #:783786855094
Inventory
$ C
Details
MFG PART #:350M
McMc Part #:TBCO350M
UPC #:783786855094
Inventory
Attributes
Features
Documentation
Attributes
Brand:Blackburn®
Bolt Size:1-5/16 x 2-11/16 in
Color:Metallic
Conductor Size:250 to 350 kcmil
Conductor Type:Stranded Copper
ETIM:EC000491
Material:Bronze Alloy
Specifications:0.717 in Split, 1-21/32 in Hex Nut
Type:Type H High Strength
Features
| Bolt and nut of high-strength corrosion resistant bronze alloy |
| Pressure bar is copper through 40H, copper alloy for 350 kcmil and above |
| Bolt and nut of hex design up to 350 kcmil |
| Split-bolt connector made of metallic bronze alloy for use on copper conductors |
| 1/0 AWG stranded conductor range min tap with one max main |
| 350 kcmil to 250 kcmil conductor range for equal main and tap |
| 1 Piece/Pack |
