CU250
Blackburn®* Actual product may vary from image
Type CU Copper Splice, Long Barrel, 3-3/8 Inch Length, Max 35kV, Wire Size 250 kcmil, Tin Plated, Die Color Code Yellow
Details
MFG PART #:CU250
McMc Part #:TBCOCU250
UPC #:783786132232
Inventory
$ C
Details
MFG PART #:CU250
McMc Part #:TBCOCU250
UPC #:783786132232
Inventory
Attributes
Features
Documentation
Attributes
Brand:Blackburn®
Barrel Type:Long
Color:Yellow
Conductor Size:250 kcmil
Conductor Type:Copper
ETIM:EC001059
Finish:Tin Plated
Length:3-3/8 in
Material:Copper
Specifications:1/2 in Stud
Type:Type CU Heavy Duty
Voltage Rating:35 kV
Features
| Made of high conductivity seamless copper tubing, tin plated for corrosion-resistance |
| Specifically chamfered barrel for ease of installation |
| Color coded for matching die identification |
| Can be used for medium voltage application up to 35 kV provided proper insulation techniques are used |
| Heavy duty design which permits additional crimp for added mechanical strength |
| For use with copper conductor AWG, stranded, flexible cable, welding cable and portable cord |
