460C7W
Leviton®* Actual product may vary from image
60 Amp, 480 Volt 3-Phase, 3P, 4W, North American Pin & Sleeve Connector, Industrial Grade, IP67, Watertight - RED
Details
MFG PART #:460C7W
McMc Part #:LEVI460C7W
UPC #:078477838754
Inventory
$ E
Details
MFG PART #:460C7W
McMc Part #:LEVI460C7W
UPC #:078477838754
Inventory
Attributes
Features
Documentation
Attributes
Brand:Leviton®
Amperage Rating:60 A
Color:Red
Dimensions:4.41 in Dia x 11.26 in L
Enclosure:IP67
Frequency Rating:50/60 Hz
Grade:Industrial
Material:Valox® 357
Number of Poles:3
Number of Wires:4
Series:Series II
Temperature Rating:-40 to 60 deg C
Terminal Type:Screw
Type:North American Configuration Watertight
Voltage Rating:480 V AC, 480 VAC
Features
| Rugged housing, made of superior performance PBT, provides maximum corrosion protection and makes the device more resistant to impact, abuse and temperature extremes and V-0 flame rated and superior UV stability |
| Watertight chloroprene onion skin grommet provides a precise, reliable seal at the cable entry point |
| Rear terminals, raised lettering identification |
| Calibrated, self-adjusting contacts |
| Front terminals, raised lettering identification |
| Rugged housing, provides maximum corrosion protection and makes the device more resistant to impact, abuse and temperature extreme |
| Certified for current interrupting at full rated current |
| Contact carrier resists arcing and internal heat build up |
| Zinc-coated steel terminal screws on 20A and 30A devices |
| Dependable, clean brass construction for long life, reliable electrical contact, maximum conductivity, and corrosion resistance |
