5100P9W
Leviton®* Actual product may vary from image
100 Amp, 120/208 Volt 3PY, IEC 309-1 & 309-2, 4P, 5W, North American-Rated Pin & Sleeve Plug, Industrial Grade, IP67, Watertight, - Blue
Details
MFG PART #:5100P9W
McMc Part #:LEVI5100P9W
UPC #:078477838969
Inventory
$ E
Details
MFG PART #:5100P9W
McMc Part #:LEVI5100P9W
UPC #:078477838969
Inventory
Attributes
Features
Documentation
Attributes
Brand:Leviton®
Amperage Rating:100 A
Color:Blue
Dimensions:5 in Dia x 12.3 in L
Enclosure:IP67
Frequency Rating:50/60 Hz
Grade:Industrial
Material:Valox® 357
Number of Poles:4
Number of Wires:5
Series:Series II
Temperature Rating:-40 to 60 deg C
Terminal Type:Screw
Type:Watertight
Voltage Rating:120/208 V AC, 120/208 VAC
Features
| Rugged housing, made of superior performance PBT, provides maximum corrosion protection and makes the device more resistant to impact, abuse and temperature extremes and V-0 flame rated and superior UV stability |
| Solid brass pins |
| Reinforced nylon contact carrier |
| Stainless steel terminal screws on 100 A devices |
| Certified for current interrupting at full rated current |
