2RC10
Sta-Kon®* Actual product may vary from image
Nylon-Insulated Butt Splice, Length 1.26 Inches, Width .28 Inches, Maximum Insulation Diameter .210, Wire Range #12-#10 AWG, Color Yellow, Copper, Tin Plated
Details
MFG PART #:2RC10
McMc Part #:TBCO2RC10
UPC #:786210800226
Inventory
$ C
**Must be ordered in quantities of 50**
Details
MFG PART #:2RC10
McMc Part #:TBCO2RC10
UPC #:786210800226
Inventory
Attributes
Features
Documentation
Attributes
Brand:Sta-Kon®
Color:Yellow
Conductor Size:12 to 10 AWG
Dimensions:0.28 in Dia
ETIM:EC001059
Finish:Electro-Tin Plated
Length:1.26 in
Material:Copper
Series:RC Series
Specifications:0.21 in Maximum Insulation, 0.04 in Stock
Temperature Rating:105 deg C
Type:Nylon Insulated
Voltage Rating:600 VAC
Features
| Nylon insulated with electro tin plated |
| Wires are laid side by side in the connector and the splice connection is complete in one crimp |
| Color coded according to wire size |
| Nylon insulated splices meet or exceed the requirements of MIL-T-7928 |
| These splices are color coded according to wire size |
