A18-8F
Sta-Kon®* Actual product may vary from image
Non-Insulated Fork Terminal, Length 0.75 Inches, Width 0.31 Inches, Bolt Hole #8, Wire Range #22-16 AWG, Copper, Tin Plated, 100 Pieces
Details
MFG PART #:A18-8F
McMc Part #:TBCOA188F
UPC #:786210803012
Inventory
$ C
**Must be ordered in quantities of 100**
Details
MFG PART #:A18-8F
McMc Part #:TBCOA188F
UPC #:786210803012
Inventory
Attributes
Features
Documentation
Attributes
Brand:Sta-Kon®
Barrel Type:Brazed Seam/Serrated
Color:Metallic
Conductor Size:22 to 16 AWG
ETIM:EC001052
Finish:Electroplated Tin
Length:3/4 in
Material:Copper
Series:A Series
Specifications:0.27 in Clearance
Stud Size:#8
Temperature Rating:150 deg C
Tongue Size:0.31 in W x 0.02 in THK
Tongue Type:Fork
Type:Non-Insulated
Voltage Rating:600 VAC
Features
| Non-insulated fork terminals are made of electrolytic copper for high conductivity |
| They can be installed with crimping tools having a single indentor or double indentor recommended for solid wire |
| Brazed seam barrel is serrated for high pull-out value |
| Serrated barrel increases grip-on wire |
| WT110M, WT111M, WT112M, WT2000, ERG4001, ERG4002 recommended tools |
