RA873
Sta-Kon®* Actual product may vary from image
Nylon Insulated Ring Terminal, Length .89 Inches, Width .31 Inches, Maximum Insulation .136, Bolt Hole #10, Wire Range #22-#16 AWG, Color Red, Copper, Tin Plated, 1,000 Pack
Details
MFG PART #:RA873
McMc Part #:TBCORA873
UPC #:786210817484
Inventory
$ C
Details
MFG PART #:RA873
McMc Part #:TBCORA873
UPC #:786210817484
Inventory
Attributes
Features
Documentation
Attributes
Brand:Sta-Kon®
Barrel Type:Insulation Grip Sleeve
Color:Red
Conductor Size:22 to 16 AWG
ETIM:EC001052
Finish:TiN Coated
Length:0.89 in
Material:Copper
Series:RA Series
Specifications:0.136 in Dia Maximum Insulation, 1/4 in Clearance, Nylon Insulation
Stud Size:#10
Temperature Rating:105 deg C
Tongue Size:0.31 in W x 0.03 in THK
Tongue Type:Ring
Type:Insulated
Voltage Rating:600 VAC
Features
| Self-insulated with high dielectric strength nylon sleeves |
| An inner bronze insulation grip sleeve lengthens the flexing radius of the conductor and eliminates conductor creep |
| Made of copper and has electro-tin plating for high conductivity/corrosion resistance |
| 1000 pieces/pack |
