RC10-38

Sta-Kon®

* Actual product may vary from image

Nylon Insulated Ring Terminal, Length 1.27 Inches, Width .59 Inches, Maximum Insulation .210, Bolt Hole 3/8 Inch, Wire Range #12-#10 AWG, Color Yellow, Copper, Tin Plated

Details

MFG PART #:RC10-38

McMc Part #:TBCORC1038

UPC #:786210804453

Inventory

$ C
**Must be ordered in quantities of 50**

Details

MFG PART #:RC10-38

McMc Part #:TBCORC1038

UPC #:786210804453

Inventory

Attributes

Brand:Sta-Kon®
Barrel Type:Insulation Grip Sleeve
Color:Yellow
Conductor Size:12 to 10 AWG
ETIM:EC001052
Finish:TiN Coated
Length:1.27 in
Material:Copper
Series:RC Series
Specifications:0.21 in Dia Maximum Insulation, 0.35 in Clearance, Nylon Insulation
Stud Size:3/8 in
Temperature Rating:105 deg C
Tongue Size:0.59 in W x 0.04 in THK
Tongue Type:Ring
Type:Insulated
Voltage Rating:600 V AC, 600 VAC
