RD8-38

Sta-Kon®

* Actual product may vary from image

Nylon Insulated Large Ring Terminal, Length 1.63 Inches, Width .57 Inches, Maximum Insulation .340, Bolt Hole 3/8 Inch, Wire Range 8, Color Red, Copper, Tin Plated

Details

MFG PART #:RD8-38

McMc Part #:TBCORD838

UPC #:786210878591

Inventory

$ C

Details

MFG PART #:RD8-38

McMc Part #:TBCORD838

UPC #:786210878591

Inventory

Attributes

Brand:Sta-Kon®
Barrel Type:Brazed/Overlapped Seam
Color:Red
Conductor Size:8 AWG
ETIM:EC001052
Finish:TiN Coated
Length:1.63 in
Material:Copper
Series:RD Series
Specifications:0.34 in Dia Maximum Insulation, 0.36 in Clearance, Nylon Insulation
Stud Size:3/8 in
Temperature Rating:105 deg C
Tongue Size:0.57 in W x 0.04 in THK
Tongue Type:Large Ring
Type:Insulated
Voltage Rating:600 VAC
